Prismatic Space

Concept

IAA Space

3D space with Marble AI

uniform sampler2D sPositions;
uniform sampler2D sRotation;
uniform sampler2D sScale;
uniform sampler2D sColors;
uniform sampler2D sLookup;
uniform vec3 uFocal;
uniform vec3 uT;
uniform vec3 uR;
uniform float uS;
uniform ivec2 uPointResolution;
uniform float uScale;
uniform float uAlphaThreshold;
uniform float u_time;
// --- THE DATA BRIDGE ---
// We added 'camDist' here so the Vertex shader can send true depth to the Pixel shader.
#ifdef TD_VERTEX_SHADER
out Vertex
#else
in Vertex
#endif
{
 vec3 position;
 vec4 color;
 vec2 uv;
 vec3 conic;
 float camAngle;
 float camDist;
} Vert;
// ==========================================
// VERTEX SHADER
// ==========================================
#ifdef TD_VERTEX_SHADER
mat3 RotZYX(vec3 a) {
 vec3 c = cos(a), s = sin(a);
 return mat3(
 c.x*c.y, c.x*s.y*s.z - s.x*c.z, s.x*s.z + c.x*s.y*c.z,
 s.x*c.y, c.x*c.z + s.x*s.y*s.z, s.x*s.y*c.z - c.x*s.z,
 -s.y, s.z*c.y, c.y*c.z
 );
}
mat3 quatToMat3(vec4 q) {
 float qx = q.y, qy = q.z, qz = q.w, qw = q.x;
 float qxx = qx*qx, qyy = qy*qy, qzz = qz*qz, qxz = qx*qz, qxy = qx*qy, qyw = qy*qw, qzw = qz*qw, qyz =
qy*qz, qxw = qx*qw;
 return mat3(
 vec3(1.0 - 2.0 * (qyy + qzz), 2.0 * (qxy - qzw), 2.0 * (qxz + qyw)),
 vec3(2.0 * (qxy + qzw), 1.0 - 2.0 * (qxx + qzz), 2.0 * (qyz - qxw)),
 vec3(2.0 * (qxz - qyw), 2.0 * (qyz + qxw), 1.0 - 2.0 * (qxx + qyy))
 );
}
mat3 RotScale(vec4 rot, vec3 scale, float globalScale) {
 mat3 ms = mat3(
 uS*globalScale*exp(scale.x), 0, 0,
 0, uS*globalScale*exp(scale.y), 0,
 0, 0, uS*globalScale*exp(scale.z)
 );
 return ms*quatToMat3(rot)*RotZYX(radians(uR.zyx));
}
vec3 Covariance(vec3 p, int cameraIndex, mat3 sigma) {
 mat4 camMatrix = uTDMats[cameraIndex].cam;
 vec2 limit = 1.3 * uFocal.xy;
 vec4 camPos = camMatrix*vec4(p,1.);
 camPos.xy = clamp(camPos.xy/camPos.z, -limit, limit)*camPos.z;
 float focal = uFocal.z;
 mat3 J = mat3(
 focal/camPos.z, 0., -(focal*camPos.x)/(camPos.z*camPos.z),
 0., focal/camPos.z, -(focal*camPos.y)/(camPos.z*camPos.z),
 0, 0, 0
 );
 mat3 T = mat3(uTDMats[cameraIndex].camInverse)*J;
 mat3 cov = transpose(T)*transpose(sigma)*T;
 return vec3(cov[0][0] + .3, cov[0][1], cov[1][1] + .3);
}
void main() {
 int instanceIndex = TDInstanceID();
 int vertexIndex = int(gl_VertexID/4);
 int index = instanceIndex * 1024 + vertexIndex;
 int cameraIndex = TDCameraIndex();
 ivec2 inRes = uPointResolution;
 ivec2 xy = ivec2(index % inRes.x, index / inRes.x);
 vec2 lookupData = texelFetch(sLookup, xy, 0).xy;
 int lookupIndex = int(lookupData.y);
 xy = ivec2(lookupIndex % inRes.x, lookupIndex / inRes.x);
 vec3 pos = P;
 vec2 uv = P.xy;
 vec3 conic = vec3(0.);
 vec2 ndc = vec2(0.);
 vec4 color = texelFetch(sColors, xy, 0);
 mat3 m = mat3(1);
 vec4 posData = vec4(0.), rotData = vec4(0.);
 vec3 scale = vec3(0.);

 if (color.a > 0.0 && lookupData.x > 0 && lookupData.x < 1e5) {
 posData = texelFetch(sPositions, xy, 0);
 rotData = normalize(texelFetch(sRotation, xy, 0));
 scale = texelFetch(sScale, xy, 0).xyz;
 m = RotScale(rotData, scale, uScale);
 mat3 sigma = transpose(m)*m;
 vec3 cov = Covariance(posData.xyz, cameraIndex, sigma);
 float det = cov.x * cov.z - cov.y * cov.y;
 conic = vec3(cov.z,-cov.y,cov.x)/det;
 vec2 wh = 2.*uFocal.xy * uFocal.z;
 vec2 quadwh_scr = 3.*sqrt(cov.xz);
 ndc = 2.*quadwh_scr / wh * smoothstep(0.0,0.1,uScale);
 } else { posData *= 0; color *= 0; }

 vec4 worldSpacePos = TDDeform(posData.xyz);
 vec3 camPos = (uTDMats[cameraIndex].camInverse * vec4(0.0, 0.0, 0.0, 1.0)).xyz;

 // --- TRUE DEPTH CALCULATION ---
 vec3 toCamRaw = camPos - worldSpacePos.xyz;
 vec3 toCam = normalize(toCamRaw);
 float camAngle = atan(toCam.x, toCam.z);
 vec4 projectionSpace = TDWorldToProj(worldSpacePos);
 projectionSpace /= projectionSpace.w;
 projectionSpace.xy += ndc*pos.xy*1.0;
 gl_Position = projectionSpace;
 Vert.position = projectionSpace.xyz;
 Vert.color = color;
 Vert.uv = uv;
 Vert.conic = conic;
 Vert.camAngle = camAngle;

 // Pass the true physical distance down to the Pixel Shader!
 Vert.camDist = length(toCamRaw);
}
#endif
// ==========================================
// PIXEL SHADER
// ==========================================
#ifdef TD_PIXEL_SHADER
out vec4 fragColor;
float sdCircle( vec2 p, float r ) { return length(p) - r; }
float sdFish(float i, vec2 p, float a) {
 float ds, c = cos(a), s = sin(a);
 p *= 1.3*mat2(c,s,-s,c);
 p.x *= .97 + (.04+.2*p.y)*cos(i+9.*u_time);
 ds = min(length(p-vec2(.8,0))-.45, length(p-vec2(-.14,0))-0.104);
 p.y = abs(p.y)+.13;
 return max(min(length(p),length(p-vec2(.56,0)))-.3,-ds)*.05;
}
float glow(float d, float str, float thickness){return thickness / pow(abs(d), str);}
void main()
{
 vec4 color = Vert.color;
 if (color.a == 0) discard;
 vec2 d = Vert.uv;
 vec3 conic = Vert.conic.xyz;
 float power = -.5*(conic.x * d.x * d.x + conic.z * d.y * d.y) - conic.y*d.x*d.y;
 color.a = min(0.99, color.a * exp(power));
 if (power > 0. || color.a < max(uAlphaThreshold,1./255.)) discard;
 TDCheckDiscard();
 // --- 1. PULSING NEON STAR ---
 vec2 p = Vert.uv * 2.5;
 float c = cos(u_time), s = sin(u_time);
 p *= mat2(c, s, -s, c);
 const float an = 3.14159265 / 5.0;
 const float en = 1.0 / 2.0;
 vec2 acs = vec2(cos(an), sin(an));
 vec2 ecs = vec2(cos(en), sin(en));
 float bn = mod(atan(p.x, p.y), 2.0 * an) - an;
 p = length(p) * vec2(cos(bn), abs(sin(bn)));
 p -= 0.4 * acs;
 p += ecs * clamp(-dot(p, ecs), 0.0, 0.4 * acs.y / ecs.y);
 float dist = length(p) * sign(p.x);
 float glowAmt = 0.02 / max(abs(dist), 0.001);
 glowAmt *= (0.5 + 1.5 * sin(u_time * 1.5));
 float shapeAlpha = smoothstep(0.02, 0.0, dist);
 color.a = color.a * max(shapeAlpha, glowAmt);
 color.rgb = color.rgb * shapeAlpha + (color.rgb * glowAmt * 2.0);
 // --- 2. GLOBAL SUNLIGHT RIBBONS ---
 vec2 screenPos = gl_FragCoord.xy * 0.001;
 float rc = cos(0.8);
 float rs = sin(0.8);
 vec2 rayPos = mat2(rc, rs, -rs, rc) * screenPos;

 float wave1 = pow(sin(rayPos.x * 7.0 + u_time * 0.3) * 0.5 + 0.5, 10.0);
 float wave2 = pow(sin(rayPos.x * 7.0 + u_time * 0.8 + 2.0) * 0.5 + 0.5, 15.0);

 float ribbon1 = smoothstep(0.4, 0.95, wave1);
 float ribbon2 = smoothstep(0.5, 0.98, wave2);

 vec3 rainbowColor1 = 0.5 + 0.5 * cos(u_time * 0.5 + rayPos.x * 4.0 + vec3(0.0, 2.0, 4.0));
 vec3 rainbowColor2 = 0.5 + 0.5 * cos(u_time * 0.8 + rayPos.x * 6.0 + vec3(1.0, 2.5, 4.0));

 vec3 totalRibbon = (ribbon1 * rainbowColor1) + (ribbon2 * rainbowColor2);
 float ribbonMask = max(ribbon1, ribbon2);
 color.rgb = mix(color.rgb, totalRibbon, ribbonMask * 0.2);
 // --- 3. WANDERING FIREFLY ---
 float randomSeed = fract(sin(dot(Vert.color.rgb, vec3(12.9898, 78.233, 45.164))) * 43758.5453) * 100.0;
 float t = u_time * 0.8 + randomSeed;

 vec2 fireflyPos = vec2(
 sin(t * 1.1) * cos(t * 0.83),
 cos(t * 1.3) * sin(t * 0.71)
 ) * 2.5;

 float ffDist = length((Vert.uv * 5.0) - fireflyPos) - 0.01;
 float ffGlow = 0.010 / max(abs(ffDist), 0.0005);

 float blink = pow(sin(u_time * 2.5 + randomSeed) * 0.5 + 0.5, 6.0);
 ffGlow *= blink;

 vec3 ffColor = vec3(1.7, 1.0, 0.2) * ffGlow * 3.0;
 color.rgb += ffColor;
 color.a = max(color.a, ffGlow * 0.5);
 // --- 4. DEPTH-BASED FOG (Atmospheric Perspective) ---
 // We are now using the true physical distance calculated in the Vertex Shader!
 float distFromCamera = Vert.camDist;

 // ADJUST THESE NUMBERS based on how big your 3D model is
 float fogStart = 2.0; // Where fog begins
 float fogEnd = 20.0; // Where fog is thickest

 float fogThickness = smoothstep(fogStart, fogEnd, distFromCamera);

 vec3 fogColor = vec3(0.9, 0.85, 0.7);

 color.rgb = mix(color.rgb, fogColor, fogThickness * color.a * 0.85);
 // --- OVERLAP FIX ---
 if (color.a < 0.05) discard;
 TDAlphaTest(color.a);
 fragColor = TDOutputSwizzle(color);
}
#endif
